You can check the availability of your requested electrodialysis through tests utilizing the desktop electrodialyzer.
 |
 |
●Electrodialysis test is available.
●Suitable membrane combination can be selected by changing type of cartridge.
●Conductivity, current, time and voltage are indicated. |
| MICRO ACILYZER S3 |
S3 cartridge |
|
 |
●Electrodialysis test with bipolar membrane is available.
●Normal electrodialysis test is also available.
●Suitable membrane combination can be selected by changing type of cartridge.
●Conductivity, current, time and voltage are indicated. |
|
| ACILYZER-EX3B |
|
|
| Model |
MICRO ACILYZER-S3 |
ACILYZER-EX3B |
| Functions |
Desalination, concentration |
Bipolar membrane electrodialysis |
| Indicators |
Current, voltage, desalinated and concentrated solution conductivity, time, current integration |
Current, voltage, conductivity in saline solution/acidic solution/alkaline solution, time,
current integration |
| Effective membrane area |
550cm2 |
550cm2 |
| Electric conductive area |
55cm2/cell |
55cm2/cell |
| Operating mode |
Constant voltage
(4 patterns)/constant current |
Constant voltage
(4 patterns)/constant current
|
| Terminating mode |
Current, conductivity, time |
Current, conductivity, time |
| Terminating condition |
Current: 0.00-3.00Amp
Conductivity
desalinated solution: 0.0-200mS/cm
concentrated solution: 0.0-500mS/cm
Time：0-999 |
Current: 0.00-6.00Amp
Conductivity
desalinated solution: 0.0-200mS/cm
acidic solution/alkaline solution: 0.0-500mS/cm
Time：0-999 |
| Line capacity |
150ml |
150ml |
| Standard processing capacity |
500ml/Hr(when usingAC-220-550)(*1) |
2,000ml/Hr(*2) |
| Size |
Width: 400mm
Height: 610mm
Depth: 420mm |
Width: 400mm
Height: 610mm
Depth: 420mm |
| Weight |
34kg |
35kg |
| Power |
AC 100V,single phase 50/60Hz |
AC 100V,single phase 50/60Hz |
| Power consumption |
Approx. 500W |
Approx. 550W |
| Upper temperature limit |
40℃ |
40℃ |
|
(*1) “Standard processing capacity“ indicates 95% desalination that 6% (1N) salt water can be desalinated down to 0.3% (0.05N).
(*2) “Standard processing capacity“ indicates that 7% (1N) sodium sulfate solution can be processed down to 3.5 % (0.5N) through the 3 compartment process.
